ThermaX™ PEI 9085

ThermaX™ PEI 3D Printing Filament, Made Using ULTEM™ 9085 PEI

ThermaX™ PEI 9085 is a premium filament made using ULTEM™ 9085 resin from Sabic. This resin is FAA-approved for FST applications (Flame/Smoke/Toxicity) and meets FAR 25.853 and OSU 65/65 standards.

Benefits of PEI 9085 Include:

• High thermal properties, with a Tg of 186°C

• Inherently flame-resistant with low smoke evolution and low smoke toxicity

• Long-term hydrolytic stability

• Excellent dimensional stability, low heat creep sensitivity, and a very low, uniform coefficient of thermal expansion create highly reproducible part-to-part dimensions

• Exceptional strength and modulus, even at elevated temperatures

• Good resistance to a broad range of chemicals, include automotive fluids, fully halogenated hydrocarbons, alcohols, and aqueous solutions

• Stable dielectric constant and dissipation factor over a wide range of temperatures and frequencies

Typical Applications of ULTEM 9085 PEI:

Aerospace: (FAR 25.853 and OSU 65/65 FST)

Service units, oxygen panels and components, ventilation system components, connectors, cable ducts, latches, hinges, food tray containers, door handles, and interior cladding parts.

Automotive & Transportation:

Cost-effective alternative to metal that is strong enough to replace steel in some applications yet light enough to replace aluminium like throttle bodies, ignition components, sensors, and thermostat housings.

Electronics:

Connectors, MCB components like housings, shafts and levers, hard disk drive internals, FOUPs, BiTS, PCBs, MCCB internals, Plenum devices, LCD projector internals, fuel cell components etc
