ThermaX™ PEI 1010

ThermaX™ PEI 3D Printing Filament, Made Using ULTEM™ 1010 PEI

ThermaX™ PEI 1010 is an ultra-performance filament made using ULTEM™ 1010 resin from Sabic. This material boasts some of the highest performance in the industry with excellent mechanical, thermal, and chemical resistance properties and high glass transition temperature (Tg) of 217°C, inherent flame retardancy

Benefits of ULTEM 1010 PEI Include:

• High thermal properties, with a Tg of 217°C

• Inherently flame-resistant

• Long-term hydrolytic stability

• Excellent dimensional stability, low heat creep sensitivity, and a very low, uniform coefficient of thermal expansion create highly reproducible part-to-part dimensions

• Exceptional strength and modulus, even at elevated temperatures

• Good resistance to a broad range of chemicals, include automotive fluids, fully halogenated hydrocarbons, alcohols, and aqueous solutions

• Stable dielectric constant and dissipation factor over a wide range of temperatures and frequencies

Typical Applications of ULTEM 1010 PEI:

Aerospace:

ULTEM 1010 meets FAR 25.853 and OSU 65/65 with low toxicity, smoke, and flame evolution. Item like personal service units, oxygen panels and components, ventilation system components, connectors, cable ducts, latches, hinges, food tray containers, door handles, and interior cladding parts.

Automotive & Transportation:

Cost-effective alternative to metal that is strong enough to replace steel in some applications yet light enough to replace aluminium like throttle bodies, ignition components, sensors, and thermostat housings.

Electronics:

Connectors, MCB components like housings, shafts and levers, hard disk drive internals, FOUPs, BiTS, PCBs, MCCB internals, Plenum devices, LCD projector internals, fuel cell components etc
