Metal 3D Printer

E-PLUS EP-M450

VoxelDance Slicer

Metal Powder Bed Fusion 3D Printer

With a building chamber size of 455*455*500 mm³, Shining 3D Introduces EP-M450 to the successful line of MPBF 3D printers. The new EP-M450 is a marvelous metal printer that makes the production of reliable and high quality large metallic parts viable on industrial scale without requiring any tools.

With it's user friendly software interface, one click printing ability and optional single/dual 500 Watt fiber lasers, EP-M450 takes digital additive manufacturing one step ahead in the field of large scale industrial applications.

Technology

Material type

Build volume

Spot Size

Layer Thickness

Slicer Soft.

Control Soft.

Optical System

: DMLS

: Metal Powder

: 455x455x500mm

: 80-120μm

: 20-100μm

: VoxelDance

: EP Control

: Single-200W/500W or Dual-2*200W (Optional)

Features

HIGH QUALITY
- Printed parts' density > 99.9 %, deviation in parts' mechanical properties < 5 %.
- The optimized gas flow design ensures efficient removal of smoke and splashes as well as
- achievement of uniform and consistent full size printing.
- Dynamic software with ability to divide the model into different sections like upper and lower surfaces, core areas and small areas etc. Different process parameters can be applied individually to these parts for high printed part quality.
- Repeatable positional accuracy along Z-axis of building direction ≤±5 μm.
- Overlapping deviation with dual laser printing ≤±0.1 mm. Overall mechanical properties of the printed part remains same when compared to printing results with the single laser machine.
Button
HIGH EFFICIENCY
- Build chamber size (X*Y*Z): 455*455*500 mm³, build chamber volume ＞100 L.
- Printing with increased layer thickness can be realized, increasing the production capacity.
- With in-house developed processing software (EP-Hatch), optimized scanning strategies can be achieved yielding reduced print duration.
- Optional dual laser system with 2*500 W fiber lasers increases printing efficiency by 70 %.
- Maxiumum building rate of 55 cm3/h.
- Bi-directional powder re-coating method leads to reduced re-coating time.
Button
RELIABLE
- Excellent core optic components from world-class supplier and mature process control parameter algorithm provides highest part quality.
- High quality uniform part printing due to excellent control over building environment and components.
- Tightly sealed build chamber maintains oxygen concentration <100 ppm and a stable pressure during printing.
- Sustained monitoring of powder left in feeder and ability to add powder without stopping the machine ensures uninterrupted part printing.
- Double protection of chamber door is attained due to dual gas releasing ports on top of printing chamber.
Button
COST-EFFICTIVE & EASY OPERATION
- Blow back enabled coarse and fine filtration system ensures prolonged lifetime of filter over 1000 hrs.
- Highly user friendly software interface and one-click printing technology makes printing super simplified.
- Comparability with different types of recoater blades such as ceramic, PU, alloy steel etc.
- Reduced gas consumption during printing ≤6 L/min helps reducing operation cost.
- Traceable print records after every print and real-time display of readings for various sensors.
Button
OPEN SYSTEM
- Open parameters for editing laser power, scan speed, scan direction, up and down facing surfaces etc.
- Open system ensures freedom to choose among wide range of metal powders available in market.
- Process software can be integrated with Siemens NX software to realize effective planning of design, simulation and printing path planning, within one software and highly improving the production efficiency.
- Process software supports SLC and CLI formats.
Button
